HMRS 6976: Brake -Third - 6 Compartments, 59ft o/b - Body Only

Add to Wish List Add to Compare
SKU
6976
In stock
Be the first to review this product
£0.00

Add Digital Image

Brake -Third - 6 Compartments, 59ft o/b - Body Only
More Information
More Information
Subject TypePassenger Coaching Stock
Subject SubdivisionCarriage - Bogie Gangway
Drawing TypeGeneral Arrangement
CompanySouthern Railway Co
Date27 Oct 1935
Original CompanySouthern Railway, CME Department, Carriage Drawing Office, Eastleigh
Original Drawing Number25298
Collection NameRay Chorley
Source IdentityRoll 0409
NotesScale ½ins : 1ft - Diagram 2113 - Drawing Shows Venitlators on Doors Which Were Not Fitted to Production Vehicles
Digital Image AvailabileYes
