HMRS 31227: 8ft 6ins Bogie (Heavy Type) - Duplex Bolsters Erection Diagram

Add to Wish List Add to Compare
SKU
31227
In stock
Be the first to review this product
£0.00

Add Digital Image

8ft 6ins Bogie (Heavy Type) - Duplex Bolsters Erection Diagram
More Information
More Information
Subject TypeBogie
Subject SubdivisionBogie - Carriage
Drawing TypeDiagram (Outline)
CompanyLondon & North Eastern Railway Co
Date27 Feb 1939
Original CompanyMetropolitan Railway Carriage, & Wagon Co Limited
Original Drawing Number77937
Collection NameMetropolitan Cammell
Source IdentityRoll 0451
NotesScale 1ins : 1ft - LNER 12970N & 12971N - Supercedes 11840N
Digital Image AvailabileYes
