main product photo

HMRS 31222: 8ft 6ins Bogie (Heavy Type) - Duplex Bolsters Erection Diagram

Add to Wish List Add to Compare
SKU
31222
In stock
Be the first to review this product
£0.00

Add Digital Image

8ft 6ins Bogie (Heavy Type) - Duplex Bolsters Erection Diagram
More Information
More Information
Subject TypeBogie
Subject SubdivisionBogie - Carriage
Drawing TypeDiagram (Outline)
CompanyLondon & North Eastern Railway Co
Original CompanyMetropolitan Railway Carriage, & Wagon Co Limited
Original Drawing Number75109
Collection NameMetropolitan Cammell
Source IdentityRoll 0451
NotesScale 1, 1½ & 3ins : 1ft - LNER 11830N
Digital Image AvailabileYes
